Through-tip spray cleaning restores pick force on 01005-to-Ø2.0 mm nozzles across Fuji, JUKI, Yamaha, Samsung, Panasonic and assembleon fleets — 24 pieces per cycle, no feeder downtime marathons.
Every machine photo from ph.smthelp.com. Videos verified live on our YouTube channel.
Load up to 24 mounter nozzles in the jig; the machine ultrasonically sprays cleaning media through each tip — from 01005 nozzles up to Ø2.0 mm holes — restoring pick force without dismounting feeders for hours.
| Nozzle range | Min 01005 → max Ø2.0 mm tip hole |
|---|---|
| Jig | 24 holes per cycle |
| Spray pressure | ≤0.55 MPa |
| Air supply | 0.5–0.7 MPa |
| Power | AC220V, 1 A |
| Footprint | L665 × W555 × H475 mm — desktop |
Source: S-6200 Full Automatic High-efficiency Nozzle Cleaning Machine datasheet & user manual, Southern Machinery.
The proven compact auto cleaner (legacy SCM24, now SME24) that started the family — same 24-hole jig architecture, documented down to spare parts in the installation & commissioning guide.
| Nozzle range | 01005 → Ø2.0 mm |
|---|---|
| Jig | 24 holes |
| Spray pressure | ≤0.55 MPa · air 0.5–0.7 MPa |
| Power | AC220V, 1 A |
| Size | L665 × W555 × H475 mm |
Source: SCM24 Auto Nozzle Cleaner 2019 datasheet + SCM24 Installation & Commissioning Guide, Southern Machinery.
For mixed nozzle fleets and lower volumes: batch-tube cleaning with the same media-through-tip principle, documented in the Nozzle Cleaning Machine Instructions PDF.
| Method | Immersion + through-tip cleaning media, batch tubes |
|---|---|
| Docs | Nozzle Cleaning Machine Instructions (PDF) |
Source: S-1681 Auto SMT Nozzle Cleaner presentation (2017) + shared instructions PDF.
Tell us your product mix and we will spec it — this section shows how we typically match lines to factories.
One person, one tray, 24 nozzles done. The standard cell for SMT departments chasing pick-error rates.
Long-field history, published commissioning guide and spare-part tree — lowest lifecycle risk.
Batch tubes for odd fleets: grippers, E-cap, flexible nozzles between PM rounds.
Tell us your product mix and we will spec it — this section shows how we typically match lines to factories.
No electricity in the chamber, months-long bath life, 29-inch capacity — the safe default for screen rooms.
Heated wash, 1 μm dual filtration, 90 °C monitored drying and conductivity-logged DI rinse for process-control shops.
Two 750 mm stencils per load on pure shop air — the throughput twin.
One avoided mis-pick per shift pays for consumables; the datasheets below include the utilities table.
Typical site preparation for Southern Machinery aqueous cleaning equipment. Exact utilities for each model are in its manual.
Any stable bench with board-feeder clearance; desktop 665×555 mm.
0.5–0.7 MPa dry shop air with quick connector.
AC220V 1 A — a normal outlet.
Fill chamber to level; match media to coating type (guide ships with manual).
Run a known-dirty nozzle set; inspect tips at 10×.
Click any video to load it from YouTube — nothing streams until you ask.
Official Southern Machinery datasheets, manuals and validation reports, hosted on our file server.
We return microscope before/after photos, a cycle recommendation and a quote — the same test flow used in our Schneider fixture trials.
Email info@smthelp.com WhatsApp +86 136 0256 2576
